Precision-machined, complete direct-impingement Bolt Carrier Group with a patented long-advance cam path that correctly times the rifle, finished in thin dense chrome. The patented enhanced cam pin provides consistent lock up reducing headspace variations. Match grade performance right out of the box, and a true drop-in component that will work with any barrel and gas system length.

PRECISION CAM PIN
A Precision Cam pin with tighter tolerances compared with the standard milspec component, providing improved shot to shot consistency in AR platform weapons. The cam pin head features a directional arrow for uniform lapping, and is designed to minimize upper receiver contact when not used in conjunction with the Long Advance Bolt Carrier, while providing full bolt stability and control.

CORRECTED TIMING
By correcting the legacy cam path, the bolt unlocks at 22.5 degrees rather than 20.7 degrees ensuring the cam pin is at top-dead-center where it should be, thus avoiding interference with the receiver wall aft of the the cam pin recess. By delaying unlocking by almost 2 degrees, residual  chamber pressure is reduced allowing the cartridge to fully release from the chamber wall easing extraction. The long advance cam path results in a flatter shooting platform with less recoil, even in over-gassed weapons, and smoother locking and unlocking all reducing muzzle rise.

** Depending on your setup, you may have to drop buffer weights to a carbine buffer, especially if you are running the DI carrier unsuppressed.

• CNC Precision Machined
• Heat Treated 8620 Alloy Steel
• Patented Long Advance Cam Path
• Faceted Carrier Design
• Full-Auto Rated
• Grade 8 Gas Key Screws
• Thin Dense Chrome Plated
• Lifetime Warranty
• Weight: 2lbs
