• 0.33° Tilt, 20 MOA Compensation, 70 mm Offset, 60 mm Inner Ring Distance, 85 mm Outer Ring Distance, 80 mm Base Length, 25 mm Ring Width, Fits 30 mm Diameter Tube
• Quick Release (QR) Picatinny Mount Features Tool-free Tension Adjustment, Locking QR Levers, and Squared Recoil Stops for a Secure and Repeatable Zero
• Precision CNC Machined from 6061-T6 Aluminum and Finished in a Matte Black Anodize
• 20 MOA Vertical Compensation Increases Access to Elevation Adjustment Range
• Snag-free Radiused Edges and Corners
• Lightening Cut for Reduced Weight
• Rated for .338 LAPUA Magnum

NOTE: We recommend tightening the ring top screws with a torque value of 25 inch-lb.

Specifications
Caliber: .338 Lapua Magnum
Locking Mechanism: QR Lever
Materials: 6061-T6 Aluminum, Steel
Mount Type: Picatinny
Quick Detachable: Yes
Surface Finish: Anodized; Black
Torque Value (Top Screw): 25in-lbs
Weight: 5.7 oz (162 g)

Dimensions
Base Length: 3.15 in (80 mm)
Inner Diameter: 30mm
MOA Compensation: 20
Offset Distance: 2.76 in (70mm)
Ring Distance (Inner): 2.36 in (60mm)
Ring Distance (Outer): 3.35 in (85mm)
Ring Width: 0.98in (25mm)
Tilting: 0.33°
